Equipment and Market

Production Equipment

Shower/Marble/WPC/PVC wall panel production equipment system

Relying on 15 years of research and development experience (the parent company was founded in 2007), the company has built a digital production system composed of computer high-speed gravure printing machine, automatic extrusion line and AI quality inspection system to meet the diversified needs of global customers for environmental protection building materials. Core equipment and technology are as follows:

1. Shower wall panel (Shower) equipment

Intelligent extrusion system: The use of German imported twin screw extruder (screw diameter 105mm, aspect ratio 22:1), with hydraulic forming mold, the production of and waterproof wall panel, annual capacity of 50,000 tons 1.

Flame retardant treatment line: through the UL94 V-0 fire test, the proportion of flame retardant added is accurate to ±0.3%.

2. Marble wall panel (Marble) equipment

3D printing coating line: Integrated UV curing technology (energy density ≥800mJ/cm²), to achieve marble precision 0.1mm reengraving, support 1220×3000mm large plate customization 2.

Calcium powder modification system: the raw material ratio is 62% calcium carbonate +35%PVC resin, and the mixing uniformity is > 98% through the double planetary mixer.

Heat transfer equipment: temperature control accuracy ±2℃, hot printing speed up to 15m/min, can produce high light/matte/antique and other surface effects.

3. WPC wall panel equipment

Wood-plastic blending system: equipped with automatic weighing and feeding machine (error < 0.5%), supporting the precise ratio of wood powder (60-80 mesh) and recycled plastic (ratio ≥70%) 4.

Four-dimensional vacuum molding machine: the 6-meter-long molding section achieves a density of 0.8-1.2g/cm³, a closed cell ratio of > 85%, and a bending strength of 35MPa.

Dust-free cutting center: Diamond saw blade imported from Germany (speed 3000rpm), cutting accuracy ±0.3mm, support V-groove /45° bevel processing.

4. PVC wall panel equipment

High-speed gravure printing line: equipped with 10-color gravure printing machine (printing speed 120m/min), to achieve accurate overprinting of marble/wood grain/geometric pattern3.

Online laminating unit: PET film bonding strength > 3N/mm (GB/T 2792 standard), scratch resistance up to 4H (ASTM D3363).

Foaming control system: micro-foaming density 0.4-0.7g/cm³, thermal conductivity ≤0.15W/(m·K), in line with building energy conservation standards.

Production Market

We have customers in both domestic and overseas markets. Linda Sales Manager can speak fluent English to facilitate good communication. Our main sales markets:North America 30.00%, Western Europe 25.00%, Oceania 5.00%, South America 5.00%, Southeast Asia 15.00%, Middle East 10.00%, Eastern Europe 5.00%, East Asia 5.00%.
